Product Features

• Fully double skinned and insulated construction in AISI 304 stainless steel
• Moulded deep drawn wash tank with rounded corners
• 2x wash arms in AISI 304 stainless steel
• 2x rinse arms in AISI 304 stainless steel
• Counterbalanced and insulated door with gasket
• Usable wash height 415mm
• Double rack system with extractable support, washing 2 baskets simultaneously:
• Upper basket for plates/saucers (2 height adjustment levels)
• Bottom basket for glasses/cups
• Automatic partial water exchange in the wash tank via the drain pump
• Rinse booster pump offers (HTR) rinse via atmospheric boiler
• Three-stage dynamic filter system
• Drain pump
• WRAS compliant break tank
• Fully electronic control panel with soft touch buttons
• 7 tailored wash programs with optional freshwater and extended rinse options
• Wash pump with soft start
• Thermostop for guaranteeing the rinse water temperature
• Stand-by function to limit the activity of the heating elements during periods of non-use
• Self cleaning cycle on drain down
• Self-diagnosis system with error messages
• Electronically controlled peristaltic detergent and rinse aid dispensers
• Included 1 x Flat bottomed basket, 1 x Basket for dishes, 1x Cutlery basket, 1 x Wire basket for trays

• Basket dimensions: 2 x baskets 500x500mm
• Baskets / hour: 120 max
• Upper basket usable wash height: 145 / 225mm
• Rinse system: Rinse pump and atmospheric boiler (HTR)
• Water consumption per cycle: 2.7 L
• Drain system: Drain pump and three-stage dynamic filter
• Continuous water softener: Integrated
• Tank: capacity / heating element: 11 L / 2.0 kW
• Boiler: capacity / heating element: 6 L / 5 - 3.3 - 2.0 kW
• Dimensions (WxDxH): 600x600x820mm
• Power supply / Power installed: 230V 1N 50Hz / 5.7 kW (3 Phase available)
